Silicone rubber sheet medical grade Conductive silicon sheet

Silicone rubber sheet medical grade Conductive silicon sheet

$29.50 USD
$32.00 USD $29.50 USD
Sale Sold out
  1. Conductive silicone sheets are used for their electrical conductivity and heat resistance in various industrial applications.
  2. The sheet is typically made of a silicone material with conductive particles or fibers added to enhance its conductivity.
  3. Conductive silicone sheets are used in electronic and electrical applications where electrical charges need to be dissipated and/or heat needs to be transferred.
  4. They can be customized in terms of thickness, hardness, and conductivity level to suit different applications.
  5. Proper storage and handling is important to ensure effective and consistent performance.
View full details

It has sealing and water vapor sealing ability. It has good electromagnetic shielding, and can provide good conductivity under certain pressure. lt has high and low temperature resistance and electrolytic corrosion resistance

Test standard Unit 8520 8700 8710 8800 8812 8813 8817
base material --- --- si si si si si si si
Conductive filling material --- --- --- Ag/Cu Ag/A1 Ag/Ni Ni/C Ni/C Ni/C
Volume resistivity MIL-DTL-83528C mOhm --- 2 8 15 8 8 12
cm
Density No curing --- g/cm³ 0.9 2.5 1.7 2/6 2 1.9 1.6
After curing ISO 2781 1.1 2.9 1.9 3.1 2.2 2.1 1.9
Hardness ISO 7619 shore 40 55 65 55 80 73 63
A
Tensile strength ISO 37 Mpa 5.6 2.1 2 2.9 2.8 2.5 2.6
Largest elongation ISO 37 % 570 310 140 240 100 170 260
Tear strength ISO 34-1C N/mm 24 12 14 14 13 15 16
The matAfter moldingEffect
of shieldingcan		 0.3-9Ghz Nolatocavity to cavity testmethod dB --- --- 70 107 --- --- ---
0.3-20Ghz 75 --- --- 130 130 110

Excellent flame retardant. Goodelectrical insulation performance.Good flexibility, high compression rate

Surface fit

Good flexibility high compression rate

Excellent flame retardant

Good electrical insulation

type Color Qi electric breakdownPressure
(VAC)		 Thermal limit@50psi
(C-inW)		 The volume resistance
(ohm-cm)
Tinda500 Brown >6000 0.45 1022
Tinda5000 Double Claro >6000 0.35 1022
Tinda100 Whtie >6000 -- 1022
Tinda300 Yellow >6000 0.53 1022
Tinda400 Gray >5500 0.63 1022
Tinda3000 Gray >6000 0.55 1022
TindaK52-1 Light amber 4200 0.13 4x1014
TindaK52-2 Light amber 7800 0.22 4x1014
TindaK52-3 Light amber 9000 0.31 4x1014
